Rotary Hanger Rotating Hanger Blasting System
Rotary Hanger shot blasting machine is designed for cleaning, descaling, rust removal, and surface preparation of hanging components. The rotating hanger system helps expose part surfaces evenly to abrasive blasting, supporting consistent cleaning quality for production and maintenance applications.
Product Overview
Rotary Hanger shot blasting improves surface quality through controlled abrasive impact while components are suspended and rotated inside the blasting chamber. This process is suitable for cleaning castings, fabricated parts, forged parts, and components with complex shapes that require even blasting coverage.
PT Ferro Servita supports customers with machine selection, abrasive media recommendation, spare parts supply, installation support, and after-sales technical service for reliable shot blasting performance.
Main Advantages
Fast Blasting Cycle
Supports efficient batch finishing for small and medium components.
Uniform Surface Finish
Helps produce consistent deburring, smoothing, and polishing results.
Flexible Media Use
Compatible with ceramic, porcelain, plastic, corncob, walnut, and compound processes.
Production Support
Suitable for continuous production, maintenance, and finishing workflow improvement.
Technical Data
Product Specification
| Model Type | TRH-5A | TRH-9A |
|---|---|---|
| Max. Diameter of Workpiece Hanger | 500 mm | 650 mm |
| Height of Workpiece Hanger | 600 mm | 1 100 mm |
| Max. Loading Weight per Hanger | 50 kg | 80 kg |
| Max. Single Workpiece Weight | 10 kg | 15 kg |
|
Average Cycle Time (e.g. cast iron workpieces) |
60 sec | 60 sec |
| Number of Blast Wheel & Capacity | 2 × 7.5 Hp (5.5 kW) | 2 × 20 Hp (15 kW) |
| Air Consumption | 18 cfm at 6 bar | 12 cfm at 6 bar |
| Total Power Requirements | 23 Hp (17.05 kW) | 56.5 Hp (42.4 kW) |
| Machine Dimensions | Width 1 500 mm | Width 1 900 mm |
| Length 2 400 mm | Length 2 700 mm | |
| Height 3 800 mm | Height 4 600 mm |
Applications
Recommended Usage
Rotary hanger blasting systems provide reliable surface treatment performance through controlled workpiece rotation and uniform abrasive exposure. Suitable for complex metal components, these systems support effective cleaning, rust removal, descaling, and surface preparation while maintaining consistent quality in industrial production processes.
Recommended Abrasive Media
Steel Shot
General Cleaning
Steel Grit
Heavy Descaling
Cut Wire
Precision Finishing
Stainless Steel Shot
Stainless Components
Additional metallic abrasive media options can be selected according to workpiece material, cleaning requirements, and required surface finish.
